Description:

• The best plunge-cut saw we have ever built.
• Maximum flexibility thanks to flat housing for minimum wall distance
• Even more precise thanks to angle setting with snap-in points and indentation (-1° and/or 47°)
• Guide wedge for safer work and simple positioning in existing joint
• Good view of scribe line and saw blade thanks to the new flush and moveable viewing window
• Improved dust extraction thanks to the new shape of the extraction duct
• Simpler operation with the double cutting depth scale (with/without guide rail)
• More benefits: splinterguard, FastFix, play adjustment without the need for tools, quick brake, etc.
• Precise circular in materials up to 55 mm thick
• Cutting interior doors to length using guide rail and circular saw
• Manufacturing expansion joints in parquet flooring and false joints
• Cutting chipboard to size
• Cutting and processing plasterboard

Technical Specification:

Power consumption: 1200 W
Idle engine speed: 2000-5200 min-1
Saw blade diameter: 160 mm
Inclination: -1 / +47 °
Cutting depth: 0-55 mm
Cutting depth at 45 degrees: 0-43 mm
Cutting depth at 45°/90°: 0-43/0-55 mm
Connection Ø d/e: 27/36 mm

Supplied With:

1 x Fine tooth saw blade W48
1 x splinterguard
1 x Flag window; vision panel
1 x operation tool
1 x SYSTAINER SYS 4 T-LOC
